Cebora 553 - 10.2 Model 558 Specifications

86/89
Item No 558 - WIN TIG AC-DC 180M
TIG MMA
Mains voltage U
1
1 x 230 V 1 x 230 V
Tolerance U
1
+15% / -20% +15% / -20%
Mains frequency
50/60 Hz 50/60 Hz
Delayed fuse
16 A 16 A
Power consumed
4.4 kVA 25%
2.5 kVA 60%
2.2 kVA 100%
4.4 kVA 30%
3.3 kVA 60%
3.0 kVA 100%
Mains connection
--- ---
Cos Phi
0.99 0.99
Performance ɳ
> 85% > 85%
Consumption in stand-by
< 50 W < 50 W
Welding current range
5 ÷ 180 A 10 ÷ 130 A
X (duty cycle)
According to standard IEC 60974-1
180 A 25%
110 A 60%
100 A 100%
130 A 30%
100 A 60%
90 A 100%
Open-circuit voltage U
0
103 V 84 V
Power-on voltage Up
9.5 kV ---
Maximum welding gas pressure
6 bar / 87 psi ---
EMC emissions class
A
Overvoltage class
III
Degree of pollution according to
IEC 60664
3
Certications
CE EAC UKCA
Degree of protection
IP23S
Weight
17.5 kg
Dimensions (WxDxH)
207x500x411 mm
