CEFLA RX DC - Page 54

52
GB
INSTALLATION
RX DC X-RAY UNIT
ERROR
NUMBER
ERROR TYPE DESCRIPTION TROUBLESHOOTING
E105
E107
X-RAY HEAD
ERROR
SW fault
Try to repeat exposure. If the problem persists, replace the
X-RAY HEAD control board.
E108
COMMUNICATION
ERROR
No
communication
between head
board and base
board
Check the continuity of the arm cable.
E130
X-RAY HEAD
ERROR
Overvoltage fault
Detected too high anodic voltage. Check X-ray head board
to tubehead cable. Tubehead fault.
E131
X-RAY HEAD
ERROR
Overcurrent fault
Detected too high anodic current. Check X-ray head board
to tubehead cable. Tubehead fault.
E132
X-RAY HEAD
ERROR
Loss of anode
voltage
regulation
Detected too low anodic voltage. Check X-ray head board
to tubehead cable. X-ray head board fault.
E133
X-RAY HEAD
ERROR
Loss of anode
current regulation
Detected too low anodic current. Check X-ray head board
to tubehead cable and pantograph arm cable. X-ray head
board fault.
E134
X-RAY HEAD
ERROR
Anode voltage
not zero
Detected non zero anodic voltage during standby. Check
X-ray head board to tubehead cable. X-ray head board
fault.
E135
X-RAY HEAD
ERROR
Anode current
not zero
Detected non zero lament current during standby. Check
X-ray head board to tubehead cable. X-ray head board
fault.
E136
X-RAY HEAD
ERROR
Excessive
regulation on
lament
Detected too high lament current. Check X-ray head
board to tubehead cable. Tubehead fault.
E137
X-RAY HEAD
ERROR
Feedback not
connected (or
lament broken)
Detected too low lament current. Check X-ray head board
to tubehead cable. Filament fault.
E138
X-RAY HEAD
ERROR
O󰀨set error
during init
Detected wrong o󰀨set on analog inputs. Check X-ray head
board to tubehead cable. X-ray head board fault.
E139
POWER SECTION
ERROR
Signal and/or
power wires of
the arm cable
interrupted
Check the continuity of the arm cable. If other errors appear
after resetting the error, check in sequence: base board,
monobloc and head board.
E150 BRAKE ERROR Overvoltage fault
Detected capacitor too high voltage. X-ray head board
fault.
E151 BRAKE ERROR
Undervoltage
fault
Detected brake too low voltage. X-ray head board fault or
brake shortcircuit fault.
E152 BRAKE ERROR Overcurrent fault
Detected brake too high current. Check capacitors board
cable and brake cable. Brake shortcircuit fault.
