CEFLA RX DC - Page 55

53
GB
INSTALLATION
RX DC X-RAY UNIT
ERROR
NUMBER
ERROR TYPE DESCRIPTION TROUBLESHOOTING
E153 BRAKE ERROR
Actuator not
connected or
thermal open
Detected brake too low current. Check capacitors board
cable and brake cable. Brake fault or brake unplugged.
E154 BRAKE ERROR Brake fault
Detected non zero current during stand-by. Check
capacitors board cable and brake cable. X-ray head board
fault or brake fault.
E155 BRAKE ERROR Brake fault
Detected non zero voltage during stand-by. Check
capacitors board cable. X-ray head board fault.
E200
E201
POWER BOARD
ERROR
Overcurrent fault
Shortcircuit detected. Check the cable inside the
pantograph arm. Tubehead or power board fault.
E202
POWER BOARD
ERROR
Driver disabled
while running
Detected unexpected disable during exposure. Check
interlock.
E203
E204
POWER BOARD
ERROR
Backup timer
overow
Detected wrong exposure time. Software or hardware
error in power or head board.
E206
E211
EXTERNAL X-RAY
KEY ERROR
External X-ray
key released too
early
Hold down the key until the image has been captured. If
the problem persists, replace the X-Ray key.
E212
POWER BOARD
ERROR
FW update error Check the pantograph arm cable. Restart the device.
E300 HANDHELD ERROR
Unexpected
pressure of the
shot key
The shot key of the wired or wireless handheld unit was
active during device turning on or it was still pressed
during the 4 seconds after emission.
E301 HANDHELD ERROR
X-Ray key
released during
shoot
Hold X-Ray key pressed until exposure end.
E302
E303
HANDHELD ERROR
Handheld
communication
error
In case of wireless handheld device, the error may be
caused by communication interferences. In this case
perform the selection procedure of the free channel. In
case of wired handheld device check the cable.
E304
E306
HANDHELD ERROR Handheld error
Internal handheld error. If the error persists replace the
handheld device.
E307
COMMUNICATION
ERROR
No
communication
between wired
handheld and
base board
Check the continuity of the handheld device cable.
