1 Operational Manual
signal .(Optional)
No. Content Description
０９
Core 1 Out L.S When chosen as core 2 L.S function, used as core 2 out stop signal.
(Optional)
１０
Nozzle Guard Purge guard closed signal.(Optional)
１１
Photo Cell Photocell detects signal at auto mode.
１２
Spare Spare
１３
Spare Spare
１４
Lubrication surface in
sufficient
Lubrication oil level detecting signal, “ON” means short of oil.
１５
Spare Spare
１６
Spare Spare
１７
Spare Spare
１８
Spare Spare
１９
Spare Spare
２０
Spare Spare
２１
Spare Spare
２２
Spare Spare
２３
Ejector Back Confirm Hydraulic Ejector returns Signal.
２４
Spare Spare
２５
Spare Spare
２６
Mold injector returns Ejector backward stop proximity switch signal.
２７
M.T. Motor Overload Mold adjustment’s motor overload signal.
２８
Hyd. Motor Overload Pump motor overload signal.
２９
Spare Spare
３０
Mold Screw Count
Signal
Mold Screw counter signal input .(Optional)
３１
Mold Ad Count Sig. Mold height adjustment signal input.
３２
Inj. Front Door L.S Input signal “OFF” means robot and injection machine connected.
３３
Inj. Rear Door L.S Robot interlock signal, when “ON” mode open1 close in allowed.
３４
Clamp Cyl. Back Co. Interlock input between robot and ejector, when “ON” ejector
forward is allowed.
３５
Mold Close Confirm Confirms signal of part taken- out by robot.
３６
Mold Screw-In L.S Mold Screw forward stops L.S signal.
04/08/13
106
