Chen Hsong CDC-2000 - The Bad Products Are too Many; The Cyclic Time Is too Long

1 Operational Manual
05/02/03
180
PRODUCT COUNTR PAGE
GOOD NO. DEFECT NO. PRODUCT NO. DEFECT %
SET NO. AAAAA ＋ BBBBB = CC.C%
TOTAL NO. FFFFF GGGGG HHHHHH II.I%
SELECT LLLLLLLL MMMMMMMM
BATCH NO. NO OF DEFECTS.
SET NO. DDDDD EEEEE
TOTAL NO. JJJJJ KKKKK
SELECT NNNNNNNN OOOOOOOO
WORKING HOUR : PPPPP HR QQ MIN
AUTO. RUNNING HOUT : RRRRR HR SS MIN
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
Menu43
3.47 “067 The Bad Products Are Too Many”
(A) The defect part counting reaches the setting
“
CCCCC
”
in menu 43 when defect part
counting
“
MMMMMMMM
”
is set at semi-auto/auto mode.
(B) Remedy: Press key at manual mode to disable the alarm.
3.48 “068 The Cyclic Time is Too Long”
(A) Cycle time is longer than Tim 03 setting at auto mode.
(B) Remedy:
a) Increase the cycle time
“
AAAA.A
”
in menu 35; refer to actual cycle time
“
MMMM.M
”
in menu 02.
b) Check individual time setting.
