1 Operational Manual
PRODUCT COUNTR PAGE
GOOD NO. DEFECT NO. PRODUCT NO. DEFECT %
SET NO. AAAAA ＋ BBBBB = CC.C%
TOTAL NO. FFFFF GGGGG HHHHHH II.I%
SELECT LLLLLLLL MMMMMMMM
BATCH NO. NO OF DEFECTS.
SET NO. DDDDD EEEEE
TOTAL NO. JJJJJ KKKKK
SELECT NNNNNNNN OOOOOOOO
WORKING HOUR : PPPPP HR QQ MIN
AUTO. RUNNING HOUT : RRRRR HR SS MIN
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
Menu43
3.26 “042 Check Limit Switch of Clamping Mold”
(A) At the mold-closing if fast mold-closing signal (input 11) is ON, warning message
will appear.
(B) Remedy: Check confirmed signal (Input 11).
3.27 “043 Check Limit Switch of Core Pull 1 “
(A) In menu 06, the core in feedback setting is set at L.S.
a) Core out L.S. signal did not feedback in stroke check time.
b) Core out signal
“
Input 09) and core in signal
“
Input 08
”
are ON simultaneously.
c) Intending to do ejector forward while core out signal
“
Input 009
”
was OFF.
(B) Remedy:
a) Check circuit of Input 09, Input 08.
b) Switch to menu 06; modify the travel check time, speed pressure setting to adequate
value.
04/08/13
171
