1 Operational Manual
2.19 Theoretical Injection Pressure Curve
THEORETRICAL INJECTION PRESSURE
99%
80%
60%
40%
20%
kg/cm
2
eeee dddd cccc bbb aaa
F1 F2 F3
F4 F5
F6
F7
F8
F9 F10
Menu 18
SCREW D : AAAmm
The diagram shows the curve of theoretical injection pressure.
