2.43 Spare Timer Unit Description
2.43.1 Spare Timer Unit Description for Toggle Clamping
TIMER SETTING
TIMER SET (SEC)
CYCLE TIME ••••••••••••••••••
AAAA.A
INTERMISSION •••••••••••••••••
BBBB.B
ALARM OF FEEDING DURING MOLD OPENING •••••
CCCC.C
ALARM OF ACCUMLATOR PRESSURIZED••••••••
DDDD.D
DEFECT OUTPUT TIME ALARM •••••••••••
EEEE.E
SPARE•••••••••••••••••••••
FFFF.F
SPARE•••••••••••••••••••••
GGGG.G
EJECT-OUT PAUSE••••••••••••••••
HHHH.H
PNEUMATIC EJECTOR FORWARD STROKE •••••••
IIII.I
PNEUMATIC EJECTOR BACKWARD STROKE•••••••
JJJJ.J
EMTRUSION ••••••••••••••••••
KKK.KK
LLLL.L
MMMM.M
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
Menu35
Move cursor to set parameter of opening mold. Key in desired digits and press to
complete a correction. Code descriptions of menu 35 are as follows:
A). AAAA.A: Timer Tim 03, time for cycle time alarm
B) BBBB.B: Timer Tim 02, delay time from finishing of ejector action to next mold-closing
C) CCCC.C: Timer Tim 08, plasticizing stroke check time when plasticizing and opening mold
simultaneously. (optional)
D) DDDD.D: Spare Timer Tim 30
F) EEEE.E: Spare Timer Tim 32
