1 Operational Manual
c) Check direction of control valve for core out.
d) Check mold’s mechanism.
CORE-PULL SETTING
CORE 1 IN CORE 1 OUT
SPEED % EE II
PRESSURE % FF JJ
MODE AAAAAAAAAA CCCCCCCCCCC
POSITION BBBB.B DDDD.D
TIME SEC GGG.G KKK.K
FEEDBACK HHHHHH LLLLLL
CORE 2 IN CORE 2 OUT
SPEED % QQ UU
PRESSURE % RR VV
MODE MMMMMMMMMM OOOOOOOOOO
POSITION NNNN.N PPPP.P
TIME SEC SSS.S WWW.W
FEEDBACK TTTTTT XXXXXX
F1 F2 F3
F4 F5
F6
F7
F8
F9 F10
Menu06
3.28 “044 Check Limit Switch of Rotational Plate”
(A) Conditions:
a) Rotational plate can
’
t finish its task at given time, warning message will appear.
b) Rotation-closing signal (Input 20) and Rotation-opening signal (Input 19) are
both
“
ON
”
warning message will appear.
c) When rotational plate is closed and signal is
“
OFF
”
, warning message will appear.
(B) Remedy:
a) Check rotation-closing (input 20) and rotation-opening signal (input 19).
b) Check the directional valve of rotational pressure.
04/08/13
172
