1 Operational Manual
signal .(Optional)
No. Content Description
０９
Core 1 Out L.S When chosen as core 2 L.S function, used as core 2 out stop signal.
(Optional)
１０
Nozzle Guard Purge guard closed signal.(Optional)
１１
Material Dropping Photo
Cell
Photocell detects signal at auto mode.
１２
High pressure signal Accumulation pressurized signal.
１３
Spare Spare
１４
Spare Spare
１５
Spare Spare
１６
Spare Spare
１７
Spare Spare
１８
Spare Spare
１９
Spare Spare
２０
Spare Spare
２１
Spare Spare
２２
Spare Spare
２３
Ejector Back Confirm Hydraulic Ejector returns Signal.
２４
Spare Spare
２５
Spare Spare
２６
Mold injector returns Ejector backward stop proximity switch signal.
２７
Spare Spare
２８
Hydraulic Motor
Overload
Pump motor overload signal.
２９
Spare Spare
３０
Mold Screw Count
Signal
Mold Screw counter signal input .(Optional)
３１
Mold Ad Count Sig. Mold height adjustment signal input.
３２
Inj. Front Door L.S Input signal “OFF” means robot and injection machine connected.
３３
Inj. Rear Door L.S Robot interlock signal, when “ON” mode open1 close in allowed.
３４
Robot controls ejector
forward
Interlock input between robot and ejector, when “ON” ejector
forward is allowed.
３５
Mold Close Confirm Confirms signal of part taken out by robot.
３６
Mold Screw In L.S Mold Screw forward stops L.S signal.
04/08/13
109
