1 Operational Manual
signal .(Optional)
No. Content Description
０９
Core 1 Out L.S When chosen as core 2 L.S function, used as core 2 out stop signal.
(Optional)
１０
Nozzle Guard Purge guard closed signal.(Optional)
１１
Photo Cell Photocell detects signal at auto mode.
１２
Clamp Cyl. Cl.End Accumulation pressurized signal.
１３
Spare Spare
１４
Spare Spare
１５
Spare Spare
１６
Motor Start-Up Motor Y to running confirmation signal.
１７
Gear Pitch Signal 1 Gear pitch signal 1 confirmation signal.
１８
Gear Pitch Signal 2 Gear pitch signal 2 confirmation signal.
１９
Lock-Up Open Lock-up open confirmation signal.
２０
Lock-Up Close Lock-up close confirmation signal.
２１
Pos. Cyl. Max. Pr. Pro. Position cylinder backward confirmation.
２２
Clamp Cyl. Relief High-pressure cylinder leakage pressure switch.
２３
Ejector Back Confirm Hydraulic Ejector returns Signal.
２４
Door deceleration Pneumatic door closing deceleration signal.
２５
Door deceleration Pneumatic door opening deceleration signal.
２６
Pos. Cyl. Str. Por. Ejector backward stop proximity switch signal.
２７
Spare Spare
２８
Hyd. Motor Overload Pump motor overload signal.
２９
Hyd. Oil Temp. High Emergency stop input for pneumatic door.
３０
Mold Screw Count
Signal
Mold Screw counter signal input .(Optional)
３１
Mold Ad Count Sig. Mold height adjustment signal input.
３２
Inj. Front Door L.S Input signal “OFF” means robot in line.
３３
Inj. Rear Door L.S Robot interlock signal, when “ON” mode open1 close in allowed.
３４
Clamp Cyl. Back Co. Interlock input between robot and ejector, when “ON” ejector
forward is allowed.
３５
Mold Close Confirm Confirms signal of part taken- out by robot.
３６
Mold Screw In L.S Mold Screw forward stops L.S signal.
