1 Operational Manual
No. Content Description
７０
Boost Clamping Carriage Forward Output
７１
Core 1 In
Core 1 In Output。
７２
Core 1 Out
Core 1 Out Output。
７３
Mold Screw In
Mold Screw Forward Output。(Optional)
７４
Mold Screw Out
Mold Screw Backward Output。(Optional)
７５
Thinner
Mold Height Adjustment Forward Output。
７６
Thicker
Mold Height Adjustment Backward Output。
７７
Spare Spare
７８
Spare Spare
７９
Spare Spare
８０
Airblow Ends Airblowing Output After Mold Opening
８１
Airblow Opens Airblowing Output After Mold Setting Position
８２
Feeding Opens Plasticizing Output When Opening Mold (Optional)
８３
Core 2 In Core 2 In (Optional)
８４
Core 2 Out Core 2 Out (Optional)
８５
Pos. Cylinder Forward When injection completed at auto mode, this output will “ON”.
８６
Pos. Cylinder Backward Output signal for robot to take part out, when mold opened, this
output will “ON”.
８７
Boost
When purchasing ＤＳor double pump, this is aux. Flow rate
output.
８８
Spare Spare
８９
Spare Spare
９０
Spare Spare
９１
System Used System saving confirmation output.
９２
Blank
９３
Blank
９４
Blank
９５
Blank
９６
Blank
９７
Blank
９８
Blank
９９
Blank
１００
Blank
No. Content Description
１０１
Blank
１０２
Blank
１０３
Blank
１０４
Blank
１０５
Blank
