1 Operational Manual
E) EEEE.E: Spare Timer Tim 32
F) GGGG.G: Spare Timer Tim 05
G) HHHH.H: Spare Timer Tim 31
H) I I I I .I: Timer Tim 24, delay time for ejector action after mold opining at auto mode
I) J J J J .J: Spare Timer Tim 36
J) KKKK.K Spare Timer Tim 37
K) LLLL.L: Spare Timer Tim 33
L) MMMM.M: Spare Timer Tim 34
2.43.4 Spare Timer Unit Description for Combined Clamping
TIMER SETTING
TIMER SET (SEC)
CYCLE TIME ••••••••••••••••••
AAAA.A
INTERMISSION •••••••••••••••••
BBBB.B
ALARM OF FEEDING DURING MOLD OPENING •••••
CCCC.C
ALARM OF ACCUMLATOR PRESSURIZED••••••••
DDDD.D
DEFECT OUTPUT TIME ALARM •••••••••••
EEEE.E
SPARE•••••••••••••••••••••
FFFF.F
SPARE•••••••••••••••••••••
GGGG.G
EJECT-OUT PAUSE••••••••••••••••
HHHH.H
PNEUMATIC EJECTOR FORWARD STROKE •••••••
IIII.I
PNEUMATIC EJECTOR BACKWARD STROKE•••••••
JJJJ.J
EMTRUSION ••••••••••••••••••
KKK.KK
LLLL.L
MMMM.M
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
Menu35
Move cursor to set parameter of opening mold. Key in desired digits and press to complete a
correction. Code descriptions of menu 35 are as follows:
A). AAAA.A: Timer Tim 03, time for cycle time alarm
B) BBBB.B: Timer Tim 02, delay time from finishing of ejector action to next mold-closing
C) CCCC.C: Timer Tim 08, plasticizing stroke check time when simultaneous plasticizing and
opening mold. (optional)
