4.4 Using Printer
4.4.1 Printer‘s specification:
The printer’s specification of CDC-2000 controller is EPSON STYLUS COLOR 600 or
EPSON STYLUS COLOR.
4.4.2 Quality recording and Data Printing:
QUATILY RECORD
PROD. DEFE. CYCLE FILLE CUSH.FEED. FEED. V/P T1 T2 T3 T4 T5 T6 TC
NO. NO. TIME TIME END TIME END PR.
125742 12312 123.3 12.12 12.1 123.1 123.0 123 220 228 220 210 200 190 180
125741 12312 123.3 12.13 12.0 123.1 122.9 123 220 228 220 210 200 190 179
125740 12312 123.3 12.10 12.0 123.1
122.5 123 220 229 220 210 200 190 180
125739 12312 123.3 12.09 12.2 123.1 123.1 123 220 229 220 210 200 190 180
125738 12312 123.3 12.10 12.1 123.1
123.6 123 220 229 221 210 200 190 180
125737 12312 123.3 12.11
12.4 123.1 123.1 123 220 229 221 210 200 190 181
125736 12311 123.3 12.15 12.1 123.1 123.1 123 220 230 221 210 200 190 181
125735 12311 123.3 12.12 12.0 123.1 123.0 123 220 230 221 210 200 190 180
125734 12311 123.3 12.10 12.0 123.1 123.1 123 220 230 221 210 200 190 180
125733 12311 123.3 12.10
12.3 123.1 122.9 123 220 229 221 210 200 190 180
125732 12311 123.3 12.15 12.1 123.1 123.1 123 220 230 221 210 200 190 181
125731 12311 123.3 12.12 12.0 123.1 123.0 123 220 230 221 210 200 190 180
125730 12311 123.3 12.10 12.0 123.1 123.1 123 220 230 221 210 200 190 180
SET VALUE 123.3 12.15 12.1 129.1 123.0 123
DEVIATION ± AA.AA BB.B CCC.C DDD.D EEE
QC CONTROL Ｆ Ｇ Ｈ Ｉ Ｊ
SET
KKKKK CYCLE DATA AS STANDARD VALUE (QUALITY CONTROL): CONFIRM
EVERY
LL MOLDS SEND QUALITY RECORD DATA TO PRINTER : Ｍ
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
Menu44
(A) Move cursor to menu 44
“
LL
”
to set printing space, when the setting value is
“
1
”
, when every product produced then every quality record will be printed,
“
5
”
means printing 5 times,
“
0
”
means not printing.
