1 Operational Manual
H) M2: Third pressure setup for injection.
I) MMM.M: Third end-position setup for injection.
J) N1: Fourth speed setup for injection.
K) N2: Fourth pressure setup for injection.
L) NNN.N: Fourth end-position setup for injection.
M) O1: Fifth speed setup for injection.
N) O2: Fifth pressure setup for injection.
O) OOO.O: Fifth end-position setup for injection.
P) P1: Sixth speed setup for injection.
Q) P2: Sixth pressure setup for injection.
R) PPP.P: Sixth end-position setup for injection.
S) cccc.c: Time setup for injection from first to sixth.
2.20.7 Holding Pressure Stroke Setup:
A) Q1: First speed setup for holding-pressure.
B) Q2: First pressure setup for holding-pressure.
C) QQQ.Q: First time setup for holding-pressure.
D) R1: Second speed setup for holding-pressure.
E) R2: Second pressure setup for holding-pressure.
F) RRR.R: Second pressure setup for holding-pressure.
G) S1: Third speed setup for holding-pressure.
H) S2: Third pressure setup for holding-pressure.
J) SSS.S: Third time setup for holding-pressure.
2.20.8 Feeding and Decompression Stroke Setup:
A) T1: Decompression speed setup before feeding.
B) T2: Decompression pressure setup before feeding.
C) TTT.T: Decompression end-position setup before feeding.
D) U1: First speed setup for feeding.
E) U2: First pressure setup for feeding.
F) UUU.U: First end-position setup for feeding.
G) V1: Second speed setup for feeding.
H) V2: Second pressure setup for feeding.
I) VVV.V: Second end-position setup for feeding.
J) W1: Third speed setup for feeding.
K) W2: Third pressure setup for feeding.
L) WWW.W:
Third end-position setup for feeding.
M) X1: Decompression speed setup for feeding.
N) X2: Decompression pressure setup for feeding.
04/08/13
74
