Chroma 19020 User Manual

Multi-Channel Sync Hipot Tester 19020/19020-4/19021/19021-4/19022/19022-4
User’s Manual
7-18
4. Press STOP to stop high voltage output.
5. Press ▼ to go to IRR 2GΩ OFFSET (40MΩ) calibration.
■ Connect a 40MΩ standard resistance in between the high voltage output terminal
(HV OUTPUT) and low potential terminal (RTN/LOW) of the channel to be calibrated
on the Tester.
IRR 2GΩ OFFSET (40MΩ) Calibration Screen:
CALIBRATION
IRR 2GΩ OFFSET(40MΩ)
NEXT CH
PREV CH
CHANNEL: 1
OUTPUT READING
1.000kV 40.7MΩ
STANDARD
40MΩ
LOAD=40MΩ
REMOTE
LOCK
CORR
ERROR
1. Press START to output voltage.
2. Press numeric key 0 . ~ 9 to input actual resistance.
3. Press ENTER to confirm the input.
4. Press STOP to stop high voltage output.
5. Press ▼ to go to IRR 2GΩ FULL (200MΩ) calibration.
■ Connect a 200MΩ standard resistance in between the high voltage output terminal
(HV OUTPUT) and low potential terminal (RTN/LOW) of the channel to be calibrated
on the Tester.
IRR 2GΩ FULL (200MΩ) Calibration Screen:
CALIBRATION
IRR 2GΩ FULL(200MΩ)
NEXT CH
PREV CH
CHANNEL: 1
OUTPUT READING
1.000kV 204MΩ
STANDARD
200MΩ
LOAD=200MΩ
REMOTE
LOCK
CORR
ERROR
1. Press START to output voltage.
2. Press numeric key 0 . ~ 9 to input actual resistance.
