Chroma 19020 User Manual

Calibration Procedure
7-19
3. Press ENTER to confirm the input.
4. Press STOP to stop high voltage output.
5. Press ▼ to go to IRR 20GΩ OFFSET (400MΩ) calibration.
■ Connect a 400MΩ standard resistance in between the high voltage output terminal
(HV OUTPUT) and low potential terminal (RTN/LOW) of the channel to be calibrated
on the Tester.
IRR 20GΩ OFFSET (400MΩ) Calibration Screen:
CALIBRATION
IRR 20GΩ OFFSET(400MΩ)
NEXT CH
PREV CH
CHANNEL: 1
OUTPUT READING
1.000kV 40 8 M Ω
STANDARD
400MΩ
LOAD=400MΩ
REMOTE
LOCK
CORR
ERROR
1. Press START to output voltage.
2. Press numeric key 0 . ~ 9 to input actual resistance.
3. Press ENTER to confirm the input.
4. Press STOP to stop high voltage output.
5. Press ▼ to go to IRR 20GΩ FULL (2GΩ) calibration.
■ Connect a 2GΩ standard resistance in between the high voltage output terminal
(HV OUTPUT) and low potential terminal (RTN/LOW) of the channel to be calibrated
on the Tester.
IRR 20GΩ FULL (2GΩ) Calibration Screen:
CALIBRATION
IRR 20GΩ FULL(2GΩ)
NEXT CH
PREV CH
CHANNEL: 1
OUTPUT READING
1.000kV 2.04MΩ
STANDARD
2.00GΩ
LOAD=2GΩ
REMOTE
LOCK
CORR
ERROR
