GPIB/RS232 Interface (IEEE-488.2)
Description: The returned value “31” indicates the storage capacity of main
memory is 30 sets (1-30).
[:SOURce]:SAFety[:CHANnel]<m>:FETCh? [ < item > ] [ , < item > ]
It queries the host for the measured result when the Screen sets to On. The format of
variable <m> at the end of [:CHANnel] is 3 digits. The first digit is Frame index in the
range of 0~9 and the last two digits are Channel index in the range of 01~10
(19020/19021/19022) or 01~04(19020-4/19021-4/19022-4). When the variable is
ignored it is 001 to indicate Channel 1 of the Master. <item> is string as listed below:
The present reading of output meter
The present reading of measure meter
The time executed for RAMP
The time remained for RAMP
The time executed for DWELL
The time remained for DWELL
The time executed for TEST
When the Test Time is limited it responds the time remained.
When the Test Time is set to CONT, it responds 9.9000001E+37.
The time remained for TEST
When the Test Time is limited it responds the time remained.
When the Test Time is set to CONT, it responds 9.9000001E+37.
The time executed for FALL
The time remained for FALL
Example: Input the command SAF:CHAN003:FETH? STEP,MODE,OMET
The tester returns 1,AC,+5.000000E+02.
Description: The returned string 1,AC,+5.000000E+02 indicate the result of STEP,
MODE and output result for CH3 of Address 0 host is STEP1, AC
MODE, 0.500kV.
[:SOURce]:SAFety[:CHANnel]<m>:RESult:ALL[:JUDGment]?
It queries all judgment results when the Screen sets to On. The format of variable <m>
at the end of [:CHANnel] is 3 digits. The first digit is Frame index in the range of 0~9 and
the last two digits are Channel index in the range of 01~10 (19020/19021/19022) or
01~04(19020-4/19021-4/19022-4). When the variable is ignored it is 001 to indicate
Channel 1 of the Master. The return format is First Step Result, Second Step Result, ...,
Last Step Result. The meaning of Code is listed as below:
Code of Test Result
