Multi-Channel Sync Hipot Tester 19020/19020-4/19021/19021-4/19022/19022-4
User’s Manual
Example: Input the command SAF:CHAN003:RES:ALL?
The tester returns 116,116,116,116,116,116,116,116,116,116.
Description: The returned string is the judgment result of CH3 STEP1~STEP10 for
Address 0 host, that is PASS, PASS, PASS, PASS, PASS, PASS,P
ASS, PASS, PASS, PASS.
[:SOURce]:SAFety[:CHANnel]<m>:RESult:ALL:MMETerage?
It queries the readings of MEASURE METER in all STEPs when the Screen sets to On.
The format of variable <m> at the end of [:CHANnel] is 3 digits. The first digit is Frame
index in the range of 0~9 and the last two digits are Channel index in the range of 01~10
(19020/19021/19022) or 01~04(19020-4/19021-4/19022-4). When the variable is
ignored it is 001 to indicate Channel 1 of the Master.
Example: Input the command SAF:CHAN004:RES:ALL:MMET?
The tester returns 7.000000E-05, 5.000000E-05, 4.000000E-05,
3.000000E-05, 2.000000E-05, 1.000000E-05, 2.000000E-04,
7.000000E-05, 5.000000E-04, 3.000000E-04.
Description: The returned string is the result queried for MEASURE METER by
CH4 STEP1~STEP10 from Address 0 host, that is 0.07mA, 0,05mA,
0.04mA, 0.03mA, 0.02mA, 0.01mA, 0.20mA, 0.07mA, 0.50mA,
0.30mA.
[:SOURce]:SAFety[:CHANnel]<m>:RESult:ALL:MODE?
It queries the MODE of all STEPs when the Screen sets to On. The format of variable
<m> at the end of [:CHANnel] is 3 digits. The first digit is Frame index in the range of 0~9
and the last two digits are Channel index in the range of 01~10 (19020/19021/19022) or
01~04(19020-4/19021-4/19022-4). When the variable is ignored it is 001 to indicate
Channel 1 of the Master. The returned string is AC|DC|IR|OSC|PA.
Example: Input the command SAF:CHAN005:RES:ALL:MODE?
The tester returns OSC,AC,AC,PA,DC,DC,DC,PA,IR,IR.
Description: The returned string is the MODE setting of Address 0 host for CH5
STEP1~STEP10, that is OSC Mode, AC Mode, AC Mode, PA Mode,
DC Mode, DC Mode, DC Mode, PA Mode, IR Mode, IR Mode.
[:SOURce]:SAFety[:CHANnel]<m>:RESult:ALL:OMETerage?
It queries the readings of OUTPUT METER in all STEPs when the Screen sets to On.
The format of variable <m> at the end of [:CHANnel] is 3 digits. The first digit is Frame
index in the range of 0~9 and the last two digits are Channel index in the range of 01~10
(19020/19021/19022) or 01~04(19020-4/19021-4/19022-4). When the variable is
ignored it is 001 to indicate Channel 1 of the Master.
Example: Input the command SAF:CHAN101:RES:ALL:OMET?
The tester returns 5.100000E+01, 5.000000E+02, 1.000000E+02,
2.000000E+02, 3.000000E+02, 4.000000E+02, 5.100000E+02,
6.000000E+02, 7.000000E+02, 8.000000E+02.
Description: The returned string is the result queried for OUTPUT METER by CH1
STEP1~STEP10 from Address 1 host, that is 0.051kV, 0.500kV,
0.100kV, 0.200kV, 0.300kV, 0.400kV, 0.510kV, 0.600kV, 0.700kV,
0.800kV.
