4. To remove the seat, pull the release strap to release
the rear latches.
5. Tilt the back of the seat to the upward position.
6. The seat assembly can now be removed from the
vehicle. Grab the front seatback edge located near
the head restraint and the grab the bar on the rear
side of the seat cushion for easy removal.
Reinstalling Seat
1. To reinstall the seat: With the seat tilted forward,
align the seat’s front attachments into the detent
positions on the floor.
2. Tilt seat rearward to lock the seat back into its origi-
nal position.
NOTE:
Push downward to ensure the rear latches are in the
locked position.
3. Lift the recline handle and return the seat back to
the seating position.
WARNING!
If not properly latched, the seat could become loose.
Personal injuries could result.
Seat Release Strap
Tilt Seat Forward
Seat Removal
In Floor Seat Detents
Installing Seat
GETTING TO KNOW YOUR VEHICLE 43
