Continuous use of the Recirculation mode may make
the inside air stuffy and window fogging may occur.
Extended use of this mode is not recommended. On
systems with Manual Climate Controls, the Recircula-
tion mode (if equipped) is not allowed in Defrost mode
to improve window clearing operation. Recirculation is
disabled automatically if this mode is selected. Attempt-
ing to use Recirculation while in this mode causes the
LED on the control button to blink and then turn off.
Front Defrost Button
Press and release the Front Defrost button
to change the current airflow setting to
Defrost mode. The indicator illuminates
when this feature is on. Air comes from the
windshield and side window demist outlets. When the
defrost button is selected, the blower level may
increase. Use Defrost mode with maximum tempera-
ture settings for best windshield and side window
defrosting and defogging. Performing this function will
cause the Automatic Temperature Control (ATC) to
switch into manual mode. If the Front Defrost mode is
turned off the climate system will return the previous
setting.
Rear Defrost Button
Push and release the Rear Defrost Control
button to turn on the rear window defroster
and the heated outside mirrors (if equipped).
An indicator will illuminate when the rear
window defroster is on. The rear window defroster auto-
matically turns off after 15 minutes.
CAUTION!
Failure to follow these cautions can cause damage to
the heating elements:
•
Use care when washing the inside of the rear win-
dow. Do not use abrasive window cleaners on the
interior surface of the window. Use a soft cloth and
a mild washing solution, wiping parallel to the
heating elements. Labels can be peeled off after
soaking with warm water.
•
Do not use scrapers, sharp instruments, or abra-
sive window cleaners on the interior surface of the
window.
•
Keep all objects a safe distance from the window.
Front Temperature Control
These buttons provide the driver and passenger with
independent temperature control.
Push the red button on the faceplate or touch-
screen or press and slide the temperature bar
towards the red arrow button on the touch-
screen for warmer temperature settings.
Push the blue button on the faceplate or
touchscreen or press and slide the tempera-
ture bar towards the blue arrow button on the
touchscreen for cooler temperature settings.
SYNC Button
Press the SYNC button on the touchscreen
to toggle the Sync feature on/off. The SYNC
indicator is illuminated when this feature is
enabled. SYNC is used to synchronize the
front and rear passenger temperature settings with the
driver temperature setting. Changing the front or rear
passenger temperature setting while in SYNC will auto-
matically exit this feature. Pressing SYNC on the touch-
screen while in the Front Climate screen synchronizes
the driver and passenger temperatures only. In order to
SYNC rear temperature to driver temperature, the
touchscreen must be on the Rear Climate screen.
NOTE:
The SYNC setting is only available on the touchscreen.
Blower Control
Blower Control is used to regulate the
amount of air forced through the Climate
Control system. There are seven blower
speeds available. The speeds can be
selected using either the blower control knob on the
faceplate or the buttons on the touchscreen.
•
Faceplate: The blower speed increases as you turn
the blower control knob clockwise from the lowest
blower setting. The blower speed decreases as you
turn the blower control knob counterclockwise.
•
Touchscreen: Use the small blower icon to reduce
the blower setting and the large blower icon to
increase the blower setting. Blower speed can also
be selected by pressing the blower bar area
between the icons.
Mode Control
The airflow distribution mode can be
adjusted so air comes from the instrument
panel outlets, floor outlets, defrost outlets
and demist outlets.
Faceplate: Push the button in the center of the knob to
change the airflow distribution mode.
Touchscreen: Select Mode by pressing one of the Mode
Buttons on the touchscreen.
GETTING TO KNOW YOUR VEHICLE 73
