5�1�6�- STANDARD PHASORS�
By selecting this option, you can view the phase sequence with the standard values
(Figure 156).
Figure 156: Standardised phasor display screen�
>
>
>
<
<
<
varh
Back
Main
menu
Phasors Phase
Figure 157: Standard phasors menu�
phase 1, phase 2, phase 3, all the phases.
Note: The option selected is not displayed on the menu.
Use the keys and to select the different options.
To conrm the selection, press the key .
The menu in the lower area disappears after a few seconds. Press the key to display the
lower area again.
127
Instruction Manual
CVM-A1000 - CVM-A1500
