● When programming the number of quadrants, the conguration values::
Consumption, installation that works with 2 quadrants.
Consumption and generation, installation that works with 4 quadrants.
Use the keys and to select the different options.
To conrm the selection, press the key .
5�7�9�- QUALITY
The main setup screen of the quality parameters, shown in Figure 271, is used to select the type
of events to be congured.
Figure 271: Main quality parameter setup screen�
>
>
>
>
>
<
<
<
<
<
Q
Main
menu
Back
No. of cycles to
register
Transients
Quality
events
Figure 272: Setup menu: Quality
Use the and keys to select the different options.
To conrm the selection, press the key.
