3�5�10�- SINGLE-PHASE NETWORK MEASUREMENT, PHASE TO PHASE, WITH A 2-WIRE
CONNECTION (CVM-A1x00-ITF)�
Measurement system:
Secondary winding of the current transformer: (MC1 type transformer)
Power
Supply
L1
L2
N V
L3 L2
V
L1
V
VL1
S1 S2
S1 S2
S1
S2
L1
P1
P2
L2
L3
P1 P2 P1
P2
S1
S2
LN
P1
P2
NV
REF REF
S1 S2
P1
P2
POWER SUPPLY
VL2
LOAD
Figure 14: Phase to phase single-phase measuring with a 2-wire connection (transformer secondary: /1A, /5A or
MC1 (/0�250))�
The MC1 transformer secondary value is set to 0.250 A
26
CVM-A1000 - CVM-A1500
Instruction Manual
