5�1�7�- HARMONICS�
On this screen, Figure 158, you can view the harmonics of the parameters indicated in Table 31.
Figure 158: Harmonics screen�
>
<
>
>
>
>
>
>
<
<
<
<
<
<
1
V
A
Harmonics Even / Odd
Previous
Next
Table
view
Back
Main
menu
Figure 159: Harmonics menu�
, , , Select the types of harmonics to display, see Table 31
even harmonics , or odd.
Note: The option selected is not displayed on the menu.
Use the keys and to select the different options.
The menu in the lower area disappears after a few seconds. Press the key to display the
lower area again.
128
CVM-A1000 - CVM-A1500
Instruction Manual
