Table 31:Harmonics�
Icon Harmonics
Current harmonics L1
Current harmonics L2
Current harmonics L3
Neutral current harmonics
(19)
Harmonics of phase-neutral voltage L1
Harmonics of phase-neutral voltage L2
Harmonics of phase-neutral voltage L3
Neutral voltage harmonics
(19)
In the CVM-A1x00-FLEX version, it is unavailable in Single-Phase connection mode.
5�1�7�1�- Table display�
Figure 160: Harmonics screen, table display�
>
>
<
<
varh
Back
Main
menu
Figure 161: Table display menu�
Use the keys and to select the different options.
To conrm the selection, press the key .
129
Instruction Manual
CVM-A1000 - CVM-A1500
