4.2.- MEASUREMENT PARAMETERS
The device measures and displays different types of parameters:
 Electrical parameters,
 Quality parameters, such as transients, overvoltages, gaps and outages, according to
EN50160.
Table 10: CVM-A measurement parameters�
Parameter Units
Phases
L1-L2-L3
N
Total
III
Phase-neutral voltage Vph-N
  
Phase-phase voltage Vph-ph
 
Current A
  
Frequency Hz
(L1)
Active Power kW
 
Apparent Power kVA
 
Total Reactive Power kvar
 
Inductive Reactive Power kvarL
 
Capacitive Reactive Power kvarC
 
Power factor PF
 
Cos φ φ
 
Voltage THD % % THD V
 
Current THD % % THD A
 
Harmonic Breakdown - Voltage
(up to the 63th order harmonic)
harm V
 
Harmonic Breakdown - Current
(up to the 63th order harmonic)
harm V
 
Total Active Energy kWh
 
Total Inductive Reactive Energy kvarLh
 
Total Capacitive Reactive Energy kvarCh
 
Total Reactive Energy kvarh
 
Total Apparent Energy kVAh
 
Active Energy Tariff 1 kWh
 
Inductive Reactive Energy Tariff 1 kvarLh
 
Capacitive Reactive Energy Tariff 1 kvarCh
 
Total Reactive Energy Tariff 1 kvarh
 
Apparent Energy Tariff 1 kVAh
 
Active Energy Tariff 2 kWh
 
Inductive Reactive Energy Tariff 2 kvarLh
 
Capacitive Reactive Energy Tariff 2 kvarCh
 
Total Reactive Energy Tariff 2 kvarh
 
Apparent Energy Tariff 2 kVAh
 
Active Energy Tariff 3 kWh
 
Inductive Reactive Energy Tariff 3 kvarLh
 
Capacitive Reactive Energy Tariff 3 kvarCh
 
37
Instruction Manual
CVM-A1000 - CVM-A1500
