6�3�5�- COST VARIABLES
These parameters occupy 2 registers each.
Each unit occupies a separate register.
For these variables Function 0x04 is implemented: reading registers.
Table 40: Modbus memory map: cost variables
Parameter
Tariff 1 Tariff 2 Tariff 3 Total
Units
(35)
No. of active energy hours consumed LIII 15E0-15E1 15EC-15ED 15F8-15F9 1604-1605 1584
Cost of active energy consumed LIII 15E2-15E3 15EE-15EF 15FA-15FB 1606-1607 1586
Consumed CO
2
emissions 15E4-15E5 15F0-15F1 15FC-15FD 1608-1609 1585
No. of active energy hours generated LIII 15E6-15E7 15F2-15F3 15FE-15FF 160A-160B 1584
Cost of active energy generated LIII 15E8-15E9 15F4-15F5 1600-1601 160C-160D 1586
Generated CO
2
emissions 15EA-15EB 15F6-15F7 1602-1603 160E-160F 1585
(35)
Format of the units: Power of 10 (with sign).
6�3�6�- ANGLE VARIABLES
These parameters occupy 2 registers each.
For these variables Function 0x04 is implemented: reading registers.
Table 41:Modbus memory map: Angle variables�
Parameter Address Units
V1-V2 angle 1770-1771 Degrees x 1000 (with sign)
V2-V3 angle 1772-1773 Degrees x 1000 (with sign)
V3-V1 angle 1774-1775 Degrees x 1000 (with sign)
V1-I1 angle 1776-1777 Degrees x 1000 (with sign)
V2-I2 angle 1778-1779 Degrees x 1000 (with sign)
V3-I3 angle 177A-177B Degrees x 1000 (with sign)
6�3�7�- QUALITY VARIABLES
The instantaneous values take up 2 logs each.
The maximum and minimum values take up 4 logs, 2 for the value of the variable and the other
two for indicating the date and time of the event, in compact form.
Function 0x04 is implemented for these variables: reading logs.
Table 42: Modbus memory map: Quality variables
Parameter Symbol Instantaneous Maximum Minimum
Units
(36)
Pst Flicker L1 Pst1 FA6-FA7 FF7-FFA 104F-1052 1588
Pst Flicker L2 Pst2 FA8-FA9 FFB-FFE 1053-1056 1588
Pst Flicker L3 Pst3 FAA-FAB FFF-1002 1057-105A 1588
K-factor L1 K Factor L1 FAC-FAD 1003-1006 105B-105E 1589
K-factor L2 K Factor L2 FAE-FAF 1007-100A 105F-1062 1589
K-factor L3 K Factor L3 FB0-FB1 100B-100E 1063-1066 1589
Voltage peak factor L1 Peak_factor_VL1 FB2-FB3 100F-1012 1067-106A 158A
Voltage peak factor L2 Peak_factor_VL2 FB4-FB5 1013-1016 106B-106E 158A
Voltage peak factor L3 Peak_factor_VL3 FB6-FB7 1017-101A 106F-1072 158A
Current peak factor L1 Peak_factor_AL1 FB8-FB9 101B-101E 1073-1076 158A
Current peak factor L2 Peak_factor_AL2 FBA-FBB 101F-1022 1077-107A 158A
239
Instruction Manual
CVM-A1000 - CVM-A1500
