Table 39 (Continuation) : Modbus memory map: Voltage and current harmonics�
Parameter Voltage L1 Voltage L2 Voltage L3 Neutral Voltage
Units
(34)
29th Order harmonic 134B 137F 13B3 13E7 1581
30th Order harmonic 134C 1380 13B4 13E8 1581
31st Order harmonic 134D 1381 13B5 13E9 1581
32nd Order harmonic 134E 1382 13B6 13EA 1581
33rd Order harmonic 134F 1383 13B7 13EB 1581
34th Order harmonic 1350 1384 13B8 13EC 1581
35th Order harmonic 1351 1385 13B9 13ED 1581
36th Order harmonic 1352 1386 13BA 13EE 1581
37th Order harmonic 1353 1387 13BB 13EF 1581
38th Order harmonic 1354 1388 13BC 13F0 1581
39th Order harmonic 1355 1389 13BD 13F1 1581
40th Order harmonic 1356 138A 13BE 13F2 1581
41st Order harmonic 1357 138B 13BF 13F3 1581
42nd Order harmonic 1358 138C 13C0 13F4 1581
43rd Order harmonic 1359 138D 13C1 13F5 1581
44th Order harmonic 135A 138E 13C2 13F6 1581
45th Order harmonic 135B 138F 13C3 13F7 1581
46th Order harmonic 135C 1390 13C4 13F8 1581
47th Order harmonic 135D 1391 13C5 13F9 1581
48th Order harmonic 135E 1392 13C6 13FA 1581
49th Order harmonic 135F 1393 13C7 13FB 1581
50th Order harmonic 1360 1394 13C8 13FC 1581
51th Order harmonic 146E 1482 1496 14AA 1581
52th Order harmonic 146F 1483 1497 14AB 1581
53th Order harmonic 1470 1484 1498 14AC 1581
54th Order harmonic 1471 1485 1499 14AD 1581
55th Order harmonic 1472 1486 149A 14AE 1581
56th Order harmonic 1473 1487 149B 14AF 1581
57th Order harmonic 1474 1488 149C 14B0 1581
58th Order harmonic 1475 1489 149D 14B1 1581
59th Order harmonic 1476 148A 149E 14B2 1581
60th Order harmonic 1477 148B 149F 14B3 1581
61th Order harmonic 1478 148C 14A0 14B4 1581
62th Order harmonic 1479 148D 14A1 14B5 1581
63th Order harmonic 147A 148E 14A2 14B6 1581
(34)
Format of the units: Power of 10 (with sign).
238
CVM-A1000 - CVM-A1500
Instruction Manual
