Circutor CVM-A1500 User Manual

Table 39 (Continuation) : Modbus memory map: Voltage and current harmonics�
Parameter Voltage L1 Voltage L2 Voltage L3 Neutral Voltage
Units
(34)
47th Order harmonic 128B 12BF 12F3 1327 1581
48th Order harmonic 128C 12C0 12F4 1328 1581
49th Order harmonic 128D 12C1 12F5 1329 1581
50th Order harmonic 128E 12C2 12F6 132A 1581
51th Order harmonic 141E 1432 1446 145A 1581
52th Order harmonic 141F 1433 1447 145B 1581
53th Order harmonic 1420 1434 1448 145C 1581
54th Order harmonic 1421 1435 1449 145D 1581
55th Order harmonic 1422 1436 144A 145E 1581
56th Order harmonic 1423 1437 144B 145F 1581
57th Order harmonic 1424 1438 144C 1460 1581
58th Order harmonic 1425 1439 144D 1461 1581
59th Order harmonic 1426 143A 144E 1462 1581
60th Order harmonic 1427 143B 144F 1463 1581
61th Order harmonic 1428 143C 1450 1464 1581
62th Order harmonic 1429 143D 1451 1465 1581
63th Order harmonic 142A 143E 1452 1466 1581
Parameter Current L1 Current L2 Current L3 Neutral Current
Units
(34)
Fundamental Harm. 132E – 132F 1362 – 1363 1396 – 1397 13CA – 13CB A x 1000
2nd Order harmonic 1330 1364 1398 13CC 1581
3rd Order harmonic 1331 1365 1399 13CD 1581
4th Order harmonic 1332 1366 139A 13CE 1581
5th Order harmonic 1333 1367 139B 13CF 1581
6th Order harmonic 1334 1368 139C 13D0 1581
7th Order harmonic 1335 1369 139D 13D1 1581
8th Order harmonic 1336 136A 139E 13D2 1581
9th Order harmonic 1337 136B 139F 13D3 1581
10th Order harmonic 1338 136C 13A0 13D4 1581
11th Order harmonic 1339 136D 13A1 13D5 1581
12th Order harmonic 133A 136E 13A2 13D6 1581
13th Order harmonic 133B 136F 13A3 13D7 1581
14th Order harmonic 133C 1370 13A4 13D8 1581
15th Order harmonic 133D 1371 13A5 13D9 1581
16th Order harmonic 133E 1372 13A6 13DA 1581
17th Order harmonic 133F 1373 13A7 13DB 1581
18th Order harmonic 1340 1374 13A8 13DC 1581
19th Order harmonic 1341 1375 13A9 13DD 1581
20th Order harmonic 1342 1376 13AA 13DE 1581
21st Order harmonic 1343 1377 13AB 13DF 1581
22nd Order harmonic 1344 1378 13AC 13E0 1581
23rd Order harmonic 1345 1379 13AD 13E1 1581
24th Order harmonic 1346 137A 13AE 13E2 1581
25th Order harmonic 1347 137B 13AF 13E3 1581
26th Order harmonic 1348 137C 13B0 13E4 1581
27th Order harmonic 1349 137D 13B1 13E5 1581
28th Order harmonic 134A 137E 13B2 13E6 1581
237
Instruction Manual
CVM-A1000 - CVM-A1500
