Table 10 (Continuation ): CVM-A measurement parameters�
Parameter Units
Phases
L1-L2-L3
N
Total
III
Total Reactive Energy Tariff 3 kvarh
 
Apparent Energy Tariff 3 kVAh
 
Maximum Current Demand, Tariff 1 A
 
Maximum Active Power Demand, Tariff 1 kW
 
Maximum Apparent Power Demand, Tariff 1 kVA
 
Maximum Current Demand, Tariff 2 A
 
Maximum Active Power Demand, Tariff 2 kW
 
Maximum Apparent Power Demand, Tariff 2 kVA
 
Maximum Current Demand, Tariff 3 A
 
Maximum Active Power Demand, Tariff 3 kW
 
Maximum Apparent Power Demand, Tariff 3 kVA
 
Phase sequence

K-factor -

PST Flicker (Pst)
%

Voltage peak factor -

Current peak factor -

Voltage unbalance %

Voltage asymmetry %

Current unbalance %

Current asymmetry %

Parameter Units
Tariff:
T1-T2-T3
Total Tariff
No. of hours of active tariff hours
 
Cost COST
 
CO
2
Emissions kgCO
2
 
4�2�1�- QUALITY PARAMETERS
Power quality control requires dening the TRMS of the voltage level, subsequently used by
the device to record events. According to the EN-61000-4-30 Standard, the RMS value must
be calculated for all AC magnitudes or each cycle and refresh every ½ cycle. If the RMS value
exceeds certain programmed thresholds, this is understood as an event.
The device detects the quality events, such as overvoltages, gaps, voltage outages and tran-
sients. Figure 30 shows an example of these events.
38
CVM-A1000 - CVM-A1500
Instruction Manual
