Circutor CVM-A1500 User Manual

5�2�2�- TRANSIENTS�
The screen shown in Figure 186 displays all transients, including a brief description and the
time and date of the event.
Figure 186: Generated transients display screen�
The selected transient is indicated by highlighting the background in white.
>
>
>
>
>
<
<
<
<
<
Q
Q
←
←
i
Next
Previous
Event
Information
Main
menu
Back
Figure 187: Transients display menu�
Use the and keys to select the different options.
To conrm the selection, press the key.
If no key is pressed for 5 minutes, the display screen changes automatically to the default
screen.
142
CVM-A1000 - CVM-A1500
Instruction Manual
