Table 42 (Cont�): Modbus memory map: Quality variables
Parameter Symbol Instantaneous Maximum Minimum
Units
(36)
Current peak factor L3 Peak_factor_AL3 FBC-FBD 1023-1026 107B-107E 158A
Direct V Unbalance Direct V Unbal. FBE-FBF - - 158B
Reverse V Unbalance Reverse V Unbal. FC0-FC1 - - 158B
Homopolar V Unbalance Homopolar V Unbal. FC2-FC3 - - 158B
Direct A Unbalance Direct A Unbal. FC4-FC5 - - 158B
Reverse A Unbalance Reverse A Unbal. FC6-FC7 - - 158B
Homopolar A Unbalance Homopolar A Unbal. FC8-FC9 - - 158B
Voltage unbalance KdV FCA-FCB 1027-102A 107F-1082 158B
Voltage asymmetry KaV FCC-FCD 102B-102E 1083-1086 -
Current unbalance KdI FCE-FCF 102F-1032 1087-108A 158B
Current asymmetry KaI FD0-FD1 1033-1036 108B-108E -
(36)
Format of the units: Power of 10 (with sign).
6�3�8�- QUALITY EVENT AND DISTURBANCE METERS
Function 0x04 is implemented for these variables: reading logs.
Table 43:Modbus memory map: Quality event and disturbance meter�
Parameter Address Units
Overvoltage Meter L1 109A -
Overvoltage Meter L2 109B -
Overvoltage Meter L3 109C -
Gap Meter L1 109F -
Gap Meter L2 10A0 -
Gap Meter L3 10A1 -
Voltage outage meter L1 10A4 -
Voltage outage meter L2 10A5 -
Voltage outage meter L3 10A6 -
Transients meter L1 10A9 -
Transients meter L2 10AA -
Transients meter L3 10AB -
Note: The 12 logs must be written at once (as a group), otherwise it will respond with an error.
6�3�9�- QUALITY EVENTS ALARM FLAG
Function 0x04 is implemented for these variables: reading logs.
This variable indicates whether a quality event has occurred or not and activates a 10-second
ag on the bit describing the event.
Table 44:Modbus memory map: Quality events alarm ag
Parameter Address Description
Event alarm ag 10CC
Bit 0: Overvoltage
Bit 1: Gap
Bit 2: Outage
Bit 3: Transient
Bits 4 ��� 15: 0
240
CVM-A1000 - CVM-A1500
Instruction Manual
