The value is programmed in %.
● When programming the minimum value below which the transistor is activated:
The units and maximum and minimum values of the variables to program are shown in Table 34
● When programming the maximum value above which the transistor is activated:
The units and maximum and minimum values of the variables to program are shown in
Table 34.
Note: The maximum value must be greater than the minimum value programmed.
● When programming the connection delay (ON) of the transistor digital output:
Maximum value: 999s.
Minimum value: 0s.
● When programming the disconnection delay (OFF) of the transistor digital output:
Maximum value: 999s.
Minimum value: 0s.
● When programming the latch:
Enable the latch, Disable the latch.
The latch is selected in this parameter, i.e., the transistor digital output will be locked after it
has been tripped, even when the condition that triggered it has disappeared.
Note: If the device loses its power supply, the latch disappears.
5�7�17�2�- Impulse mode of transistor digital output
When selecting the impulse mode, Figure 299, the conguration parameters are:
The variable code that controls the transistor.
The energy meter factor.
The high and low impulse period.
208
CVM-A1000 - CVM-A1500
Instruction Manual
