6.5.- PICS MAP
PICS
Vendor Name: CIRCUTOR
Product Name: CVM-A1000 | CVM-A1500
Product Model Number: 0823
Application Software Version: 1
Firmware Revision: 1.0
BACnet Protocol Revision: 10
Product Description:
Electrical energy meter
BACnet Standardised Device Prole (Annex L)
x BACnet Application Specic Controller (B-ASC)
List all BACnet Interoperability Building supported (see Annex K in BACnet Addendum 135d):
DS-RP-B Read Property
DS-WP-B Write Property
DS-RPM-B Read Property Multiple
DM-DDB-B Dynamic Device Binding
DM-DOB-B Dynamic Object Binding
DM-DCC-B Device Communication Control
DM-RD-B Reinitialize Device
Which of the following device binding methods does the product support? (check one or more)
x Receive Who-Is, send I-Am (BIBB DM-DDB-B)
x Receive Who-Has, send I-Have (BIBB DM-DOB-B)
Standard Object Types Supported:
Analogue Input Object Type
1. Dynamically creatable using BACnet’s CreateObject service? No
2. Dynamically deletable using BACnet’s DeleteObject service? No
3. List of optional properties supported: max_pres_value min_pres_value
4. List of all properties that are writeable where not otherwise required by this standard
5. List of proprietary properties:
6. List of any property value range restrictions:
Property Identier
Object_Name max 6 characters
DESCRIPTION SYMBOL ID OBJECTS OBJECT NAME UNITS
Tensión fase-neutro
Voltage phase to
neutral
V 1 AI0 Ph2NU1 V
Corriente Current A 1 AI1 Ph1Current A
Potencia activa Active power kW 1 AI2 ActPwrPh1 kW
Potencia reactiva Reactive power kvar 1 AI3 ReactPwrPh1 kvar
Factor de potencia Power factor PF 1 AI4 PwrFactPh1 PF
Tensión fase-neutro Voltage phase to
neutral
V 2 AI5 Ph2NU2 V
Corriente Current A 2 AI6 Ph2Current A
Potencia activa Active power kW 2 AI7 ActPwrPh2 kW
260
CVM-A1000 - CVM-A1500
Instruction Manual
