7.3.- TRANSISTOR DIGITAL INPUTS/OUTPUTS
This expansion module contains 8 transistor digital inputs and 8 transistor digital outputs.
7�3�1�- CONNECTION TERMINALS
A�- Terminals on the upper face
Table 103:List of terminals on the upper face, Transistor digital inputs/outputs module�
Device terminals
1: T
1
, Digital output of transistor 1 6: T
5
, Digital output of transistor 5
2: T
2
, Digital output of transistor 2 7: T6, Digital output of transistor 6
3: T
3
, Digital output of transistor 3 8: T
7
, Digital output of transistor 7
4: T
4
, Digital output of transistor 4
9: T
8
, Digital output of transistor 8
5: COM,
Common digital outputs of transistor T
1,
T
2,
T
3 and
T
4
10: COM
, Common digital outputs of transistor T
5,
T
6,
T
7 and
T
8
1 2
3
4 5 6 7 8 9 10
Figure 341: Terminals of Transistor Digital Inputs/Outputs, upper face�
B�- Terminals on the lower face
Table 104:List of terminals on the lower face, Transistor digital inputs/outputs module�
Device terminals
11: COM, for digital inputs 16: I
5
, Digital input 5
12: I
1
, Digital input 1 17: I
6
, Digital input 6
13: I
2
, Digital input 2 18: I
7
, Digital input 7
14: I
3
, Digital input 3
19: I
8
, Digital input 8
15: I
4
,
Digital input 4
11 12 13 14 15 16 17 18 19
Figure 342:Terminals of Transistor Digital Inputs/Outputs, lower face�
278
CVM-A1000 - CVM-A1500
Instruction Manual
