Circutor CVM-A1500 User Manual

3�5�13�- SINGLE-PHASE NETWORK MEASUREMENT, PHASE TO NEUTRAL, WITH A
2-WIRE CONNECTION (CVM-A1x00-FLEX)�
Sistema de medida:
VL1
L1
N V L3 L2 V L1 V
VL1
a
b
A
B
NV REF REF
N
POWER SUPPLY
N
VREF
NREF
a
b
A
B
VREF
NREF
N
L1
C
SHLD
CARGA / LOAD
Alimentación auxiliar
Power Supply
SHLD SHLDL1 L2 L3C1 C2 C3
Figure 17: Phase to neutral single-phase measuring with a 2-wire connection (transformer secondary: /100 mV~)�
It is mandatory connect the SHLD terminal of the probe.
29
Instruction Manual
CVM-A1000 - CVM-A1500
