Circutor CVM-A1500 User Manual

Variable Name Variable type Unit
Capacitive Reactive Energy (+)
nvo_CapEnergy SNVT_elec_kwh_I (146) kVArC.h(+)
Code Resolution Values
45 0.1 -214,748,364.8.. 214,748,364.6
Apparent Energy (+)
Name Variable type Unit
nvo_AppEnergy SNVT_elec_kwh_I (146) kVA.h(+)
Code Resolution Values
46 0.1 -214,748,364.8.. 214,748,364.6
Active Energy (-)
Name Variable type Unit
nvoActEnergy_exp SNVT_elec_kwh_I (146) kW.h(-)
Code Resolution Values
47 0.1 -214,748,364.8.. 214,748,364.6
Inductive Reactive Energy (-)
Name Variable type Unit
nvoIndEnergy_exp SNVT_elec_kwh_I (146) kVArL.h(-)
Code Resolution Values
48 0.1 -214,748,364.8.. 214,748,364.6
Capacitive Reactive Energy (-)
Name Variable type Unit
nvoCapEnergy_exp SNVT_elec_kwh_I (146) kVArC.h(-)
Code Resolution Values
49 0.1 -214,748,364.8.. 214,748,364.6
Apparent Energy (-)
Name Variable type Unit
nvoAppEnergy_exp SNVT_elec_kwh_I (146) kVA.h(-)
Code Resolution Values
50 0.1 -214,748,364.8.. 214,748,364.6
Arrray 1 tipo NVT ( SNVT_str_int (37)), Unit (N/A), Resolution (1), Values (0...65,565), Bytes (31)
typedef struct {
unsigned short char_set ;
unsigned long wide_char [15] ;
} SNTV_str_int;
Name Variable type Unit
Current L1
nvo_Ph1Current SNVT_amp_ac (139) A 1
Code Resolution Values
02 1 0..65,534
Current L2
Name Variable type Unit
nvo_Ph2Current SNVT_amp_ac (139) A 2
Code Resolution Values
07 1 0..65,534
Current L3
Name Variable type Unit
nvo_Ph3Current SNVT_amp_ac (139) A 3
Code Resolution Values
12 1 0..65,534
Frequency
Name Variable type Unit
nvo_Frequency SNVT_freq_hz (76) Hz
Code Resolution Values
21 0.1 0..6553.5
Phase-Phase Voltage V12
Name Variable type Unit
nvo_Ph2PhU12 SNVT_volt_ac (138) V 12
Code Resolution Values
22 1 0..65,534
322
CVM-A1000 - CVM-A1500
Instruction Manual
