Arrray 2 tipo NVT ( SNVT_str_int (37)), Unit (N/A), Resolution (1), Values (0...65,565), Bytes (31)
typedef struct {
unsigned short char_set ;
unsigned long wide_char [15] ;
} SNTV_str_int;
Name Variable type Unit
Capacitive Reactive Energy (+)
nvo_CapEnergy SNVT_elec_kwh_I (146) kVArC.h(+)
Code Resolution Values
45 0.1 -214,748,364.8.. 214,748,364.6
Apparent Energy (+)
Name Variable type Unit
nvo_AppEnergy SNVT_elec_kwh_I (146) kVA.h(+)
Code Resolution Values
46 0.1 -214,748,364.8.. 214,748,364.6
Arrray 3 tipo NVT ( SNVT_str_int (37)), Unit (N/A), Resolution (1), Values (0...65,565), Bytes (31)
typedef struct {
unsigned short char_set ;
unsigned long wide_char [15] ;
} SNTV_str_int;
Name Variable type Unit
Phase-Neutral Voltage L1
nvo_Ph2NU1 SNVT_volt_ac (138) V 1
Code Resolution Values
22 1 0..65,534
Phase-Neutral Voltage L2
Name Variable type Unit
nvo_Ph2NU2 SNVT_volt_ac (138) V 2
Code Resolution Values
23 1 0..65,534
Phase-Neutral Voltage L3
Name Variable type Unit
nvo_Ph2NU3 SNVT_volt_ac (138) V 3
Code Resolution Values
24 1 0..65,534
Frequency
Name Variable type Unit
nvo_Frequency SNVT_freq_hz (76) Hz
Code Resolution Values
21 0.1 0..6553.5
Neutral Current
Name Variable type Unit
nvo_neutralCurrent SNVT_amp_ac (139) In
Code Resolution Values
37 1 0..65,534
Active Power III
Name Variable type Unit
nvo_ActPwOn3Ph SNVT_power_kilo (28) kW III
Code Resolution Values
16 0.1 0..6553.5
Inductive Reactive Power III
Name Variable type Unit
nvoInductPwOn3Ph SNVT_power_kilo (28) kVArL III
Code Resolution Values
17 0.1 0..6553.5
Apparent Power III
Name Variable type Unit
nvo_AppPwOn3Ph SNVT_power_kilo (28) kVA III
Code Resolution Values
36 0.1 0..6553.5
324
CVM-A1000 - CVM-A1500
Instruction Manual
