7�8�5�1�- TABLE OF “RSP_UD” TELEGRAM VARIABLES
Variables arranged by order of appearance in the telegram.
Table 172: Table of “RSP_UD” telegram variables�
Variable Format Type Units Notes
Date / Time 4 bytes type F Timestamp
Date/time of the
analyzer
measurement
L1 - L2 line voltage 2 bytes Instantaneous V
1 or 2 decimal places
of resolution
L2 - L3 line voltage 2 bytes Instantaneous V
L1 - L3 line voltage 2 bytes Instantaneous V
Line III voltage 2 bytes Instantaneous V
Network frequency Float 4 bytes Instantaneous Hz
2 decimal places of
resolution
Phase 1 current 4 bytes Instantaneous A
With sign, 0 to 3
decimal places of
resolution
Phase 2 current 4 bytes Instantaneous A
Phase 3 current 4 bytes Instantaneous A
Line III current 4 bytes Instantaneous A
Phase 1 active power 4 bytes Instantaneous kW
Phase 2 active power 4 bytes Instantaneous kW
Phase 3 active power 4 bytes Instantaneous kW
Line III active power 4 bytes Instantaneous kW
Phase 1 power factor 1 byte Instantaneous -
With sign, 2 decimal
places of resolution
Phase 2 power factor 1 byte Instantaneous -
Phase 3 power factor 1 byte Instantaneous -
Line III power factor 1 byte Instantaneous -
Active energy consumed Tariff 1 4 bytes Incremental kWh
0 to 3 decimal places
of resolution
Active energy generated Tariff 1 4 bytes Incremental kWh
Active energy consumed Tariff 2 4 bytes Incremental kWh
Active energy generated Tariff 2 4 bytes Incremental kWh
Active energy consumed Tariff 3 4 bytes Incremental kWh
Active energy generated Tariff 3 4 bytes Incremental kWh
Total active energy consumed 4 bytes Incremental kWh
Total active energy generated 4 bytes Incremental kWh
Energy meter hours Tariff 1 4 bytes Incremental horas
Energy meter hours Tariff 2 4 bytes Incremental horas
Energy meter hours Tariff 3 4 bytes Incremental horas
Total energy meter hours 4 bytes Incremental horas
Phase 1 maximum current 4 bytes Máx. Inst. A
With sign, 0 to 3 deci-
mal places of
resolution
Phase 2 maximum current 4 bytes Máx. Inst. A
Phase 3 maximum current 4 bytes Máx. Inst. A
Line III maximum current 4 bytes Máx. Inst. A
Phase 1 maximum active power 4 bytes Máx. Inst. kW
Phase 2 maximum active power 4 bytes Máx. Inst. kW
Phase 3 maximum active power 4 bytes Máx. Inst. kW
Line III maximum active power 4 bytes Máx. Inst. kW
339
Instruction Manual
CVM-A1000 - CVM-A1500
