Transistor digital outputs
(91)
Quantity 2
Type Transistor
Maximum voltage 48V
Maximum current 130 mA
Maximum frequency 1 kHz
Pulse width 1 ms
Pulse duration (Ton / Toff) 0.3 ms / 0.7 ms
Relay digital outputs
(91)
Quantity 2
Maximum voltage, open contacts 250 V ~
Maximum current 3 A
Maximum switching power 1500 VA (AC1)
Electrical working life (at full load) 3x10
4
cycles
Mechanical working life 1x10
7
cycles
Digital inputs
(91)
Quantity 2
Type Potential-free contact
Insulation 4 KV
Detection current 2 mA
Maximum short-circuit current 5 mA
Maximum voltage in open circuit
15 V
(91)
Must be connected to SELV circuit.
Modbus Communications
Field bus RS-485
Communications protocol Modbus RTU
Speed 9600 - 19200 - 38400-57600-76800-115200
Stop bits 1 - 2
Parity none - even - odd
BACnet communications
Field bus MS/TP
Communications protocol BACnet
Speed 9600 - 19200 - 38400-57600-76800-115200
Stop bits 1
Parity no parity
XML Communications: Datalogger module
Connector RJ-45
Protocol XML
Baud rate Ethernet 10BT / 100BT
User interface
Display: Type TFT colour screen
Display: Resolution VGA (640x480)
Display: Format 4:3
Display: Visible area size
CVM-A1000 CVM-A1500
3.5” 5.6”
Keyboard 3 capacitive keys
352
CVM-A1000 - CVM-A1500
Instruction Manual
