Table 185: Parameter description (A�6) ( Table 1)
Parameter Description
recordGroup
Main eld which will identify the XML as a response to the variable
register request.
period Register period. Will report on time elapsed between records.
record
Will Identify each of the records:
dateTime Date and time of the sample.
eld
Standard value register.
eldComplex Complex value register
eldARM Harmonic value register
eldFO Waveform value record
eldEVQ EVQ event register
Here are the different types of values that can be returned by this request:
 Standard value registers (voltages, currents, power, energy, etc.).
<eld>
<id> … </id>
<value> … </value>
</eld>
Table 186:Parameter description (A�6) ( Table 2)
Parameter Description
id Variable identier (device.variable)
value Value
 Complex value register (PLT, etc.).
<eldComplex>
<id> … </id>
<value> … </value>
<ags> … </ags>
</eldComplex>
Table 187:Parameter description (A�6) ( Table 3)
Parameter Description
id Variable identier (device.variable)
value Value
ags
Additional information from the variable formed by the union of one or more of the
following values:
0x0000 : The PLT is correct
0x0001 : The PLT calculation has been done with fewer samples than expected
0x0002 : The PLT calculation has been done with more samples than expected
0x0004 : The samples used in the PLT calculation do not have an equidistant
separation in the sampling window
0x0008 : Some PST used in the calculation of the PLT contain events in phase 1
0x0010 : Some PST used in the calculation of the PLT contain events in phase 2
0x0020 : Some PST used in the calculation of the PLT contain events in phase 3
0x0040 : Some PST used in the calculation of the PLT are not complete
