Circutor CVM-A1500 User Manual

Table 11 (Cont.): Events of the .EVA le.
Code Description
180C Default conguration of the Date and Time
180D Default conguration of the gain due to incorrect CRC
Default conguration of the output ... (due to incorrect CRC)
Output M0-S1
(2)
M0-S2
(2)
M0-S3
(2)
M0-S4
(2)
Code 1C00 1C01 1C02 1C03
Output M1-S1
(2)
M1-S2
(2)
M1-S3
(2)
M1-S4
(2)
M1-S5
(2)
M1-S6
(2)
M1-S7
(2)
M1-S8
(2)
Code 1C10 1C11 1C12 1C13 1C14 1C15 1C16 1C17
Output M2-S1
(2)
M2-S2
(2)
M2-S3
(2)
M2-S4
(2)
M2-S5
(2)
M2-S6
(2)
M2-S7
(2)
M2-S8
(2)
Code 1C20 1C21 1C22 1C23 1C24 1C25 1C26 1C27
Output M3-S1
(2)
M3-S2
(2)
M3-S3
(2)
M3-S4
(2)
M3-S5
(2)
M3-S6
(2)
M3-S7
(2)
M3-S8
(2)
Code 1C30 1C31 1C32 1C33 1C34 1C35 1C36 1C37
Output M4-S1
(2)
M4-S2
(2)
M4-S3
(2)
M4-S4
(2)
M4-S5
(2)
M4-S6
(2)
M4-S7
(2)
M4-S8
(2)
Code 1C40 1C41 1C42 1C43 1C44 1C45 1C46 1C47
Default conguration of the input ... (due to incorrect CRC)
Output M0-E1
(2)
M0-E2
(2)
Code 1E00 1E01
Output M1-E1
(2)
M1-E2
(2)
M1-E3
(2)
M1-E4
(2)
M1-E5
(2)
M1-E6
(2)
M1-E7
(2)
M1-E8
(2)
Code 1E10 1E11 1E12 1E13 1E14 1E15 1E16 1E17
Output M2-E1
(2)
M2-E2
(2)
M2-E3
(2)
M2-E4
(2)
M2-E5
(2)
M2-E6
(2)
M2-E7
(2)
M2-E8
(2)
Code 1E20 1E21 1E22 1E23 1E24 1E25 1E26 1E27
Output M3-E1
(2)
M3-E2
(2)
M3-E3
(2)
M3-E4
(2)
M3-E5
(2)
M3-E6
(2)
M3-E7
(2)
M3-E8
(2)
Code 1E30 1E31 1E32 1E33 1E34 1E35 1E36 1E37
Output M4-E1
(2)
M4-E2
(2)
M4-E3
(2)
M4-E4
(2)
M4-E5
(2)
M4-E6
(2)
M4-E7
(2)
M4-E8
(2)
Code 1E40 1E41 1E42 1E43 1E44 1E45 1E46 1E47
1E48 Default conguration of the quality parameters due to incorrect CRC
2000 Power Supply ON
2001 Power Supply OFF
2002 Reset with command
3000 Detection in Expansion module 1 of the digital Inputs / Outputs module
3001 Detection in Expansion module 2 of the digital Inputs / Outputs module
3002 Detection in Expansion module 3 of the digital Inputs / Outputs module
3003 Detection in Expansion module 4 of the digital Inputs / Outputs module
3010 Detection in Expansion module 1 of the analogue Inputs / Outputs module
3011 Detection in Expansion module 2 of the analogue Inputs / Outputs module
3012 Detection in Expansion module 3 of the analogue Inputs / Outputs module
3013 Detection in Expansion module 4 of the analogue Inputs / Outputs module
3020 Detection in Expansion module 1 of the Lonworks communication module
3021 Detection in Expansion module 2 of the Lonworks communication module
3022 Detection in Expansion module 3 of the Lonworks communication module
3023 Detection in Expansion module 4 of the Lonworks communication module
3030 Detection in Expansion module 1 of the datalogger module
3031 Detection in Expansion module 2 of the datalogger module
3032 Detection in Expansion module 3 of the datalogger module
3033 Detection in Expansion module 4 of the datalogger module
3040 Detection in Expansion module 1 of the probus module
3041 Detection in Expansion module 2 of the probus module
42
CVM-A1000 - CVM-A1500
Instruction Manual
