2-321
Catalyst4500 Series SwitchCiscoIOS Command Reference—Release 12.2(18)EW
78-16201-01
Chapter2Cisco IOS Commands for the Catalyst 4500 Series Switches
show ip mroute
Other counts:Total/RPF failed/Other drops(OIF-null, rate-limit etc)
Group:224.2.136.89, Source count:1, Group pkt count:29051
Source:132.206.72.28/32, Forwarding:29051/-278/1186/0, Other:85724/8/56665
Switch#
This example shows how to display summary information:
Switch# show ip mroute summary
IP Multicast Routing Table
Flags: D - Dense, S - Sparse, s - SSM Group, C - Connected, L - Local,
P - Pruned, R - RP-bit set, F - Register flag, T - SPT-bit set,
J - Join SPT, M - MSDP created entry, X - Proxy Join Timer Running
A - Advertised via MSDP, U - URD, I - Received Source Specific Host
Report
Outgoing interface flags: H - Hardware switched
Timers: Uptime/Expires
Interface state: Interface, Next-Hop or VCD, State/Mode
Switch#
Table2-16 describes the fields shown in the output.
Table2-16 show ip mroute Field Descriptions
Field Description
Flags: Information about the entry.
D - Dense Entry is operating in dense mode.
S - Sparse Entry is operating in sparse mode.
s - SSM Group Entry is a member of an SSM group.
C - Connected Member of the multicast group is present on the directly connected
interface.
L - Local Switch itself is a member of the multicast group.
P - Pruned Route has been pruned. This information is retained in case a
downstream member wants to join the source.
R - Rp-bit set Status of the (S,G) entry; is the (S,G) entry pointing toward the RP.
The R - Rp-bit set is typically a prune state along the shared tree
for a particular source.
F - Register flag Status of the software; is the software registered for a multicast
source.
T - SPT-bit set Status of the packets; have the packets been received on the
shortest path source tree.
