ASR-920-12SZ-IMSpecification
-18 VDC to -32 VDC or -40 VDC to -72 VDCVoltage Range
-24 VDC/-48 VDC/-60 VDCNominal Voltage Range
375 WMaximum Power
40º C to 70º C
Operating Temperature
4 alarm dry contact inputs (normally open)
LED indicators for critical, major, and minor
alarms
Alarms
For more information on these IM modules, see the
Cisco ASR 903 Aggregation Series Router Hardware
Installation Guide .
For more information on the supported IMs, see the
Cisco ASR920 Data sheet.
Supported Interface Modules
Front or rear rail 19 or 23 inches
ETSI 300 mm open cabinet
Wall mount
Mounting option
12x1G and 4x10G/1G portsPort Configuration
4x10G SFP+ Port [12:15]
4x1G SFP Port [8:11]
8x1G PoE RJ45/Cu ports [0:7]
Port Numbering
Ports 12 to 15 are Dual Rate portsCombo Ports
Link/Activity/FaultCopper/1G/10G Port LEDs
Four temperature sensorsTemperature Sensors
External ports for 1PPS/TOD1PPS/ToD
Provides power over EthernetPoE
Connects to the external GPSGNSS
Cisco ASR-920-12SZ-IM Aggregation Services Router Hardware Installation Guide
7
Cisco ASR 920 Series Aggregation Services Router Overview
SFP+ Ports
