Cisco ASR 9901 Hardware Installation Guide

Table 11: 2-Port 10 Gigabit Ethernet Modular Port Adapter LEDs
MeaningStateColorLED Label
Port is not enabled.OffOffA/L
Port is enabled and the link is up. The MPA A/L LED will blink green when there
is traffic activity.
OnGreen
Port is enabled and the link is down.OnAmber
Modular port adapter power is off.OffOffSTATUS
Modular port adapter is ready and operational.OnGreen
Modular port adapter power is on and good, and the modular port adapter is being
configured.
OnAmber
1-Port 40 Gigabit Ethernet Modular Port Adapter
The 1-Port 40 Gigabit Ethernet modular port adapter provides a cage for a QSFP+ Ethernet optical interface
module that operates at a rate of 40 Gbps.
The QSFP cage on the 1-Port 40 Gigabit Ethernet modular port adapter has an adjacent Link LED visible on
the front panel. The Link LED indicates the status of the associated QSFP port, as described in Status LEDs,
on page 122 section.
The following figure shows an example of the front panel of the 1-Port 40 Gigabit Ethernet modular port
adapter.
Cisco ASR 9901, ASR 9001, and ASR 9001-S Routers Hardware Installation Guide
78
Installing Modules and Cables in the Chassis
1-Port 40 Gigabit Ethernet Modular Port Adapter

Cisco ASR 9901 Specifications

General

Chassis Height	1 RU
Rack Mounting	Yes
Redundancy	Yes
Operating System	Cisco IOS XR
Switching Capacity	Up to 1.2 Tbps
Memory	16 GB
Power Supply	Dual redundant AC or DC
Interfaces	10GE, 100GE
Operating Temperature	0 to 40°C (32 to 104°F)
Input Voltage	100-240V AC
Power Consumption	Varies based on configuration
Storage	64 GB SSD
Humidity	5% to 95% (non-condensing)
