RP Front Panel Indicators
The RP on the Cisco ASR 9901 has 9 discrete LED indicators for display of system information. The RP on
the Cisco ASR 9001 has 8 discrete LED indicators for display of system information.
The following table lists the display definitions of the discrete LEDs on the RP front panel as well as the
normal LED states on the power modules (AC or DC) and the fan tray after a successful system startup.
Table 17: RP Discrete LED Display Definitions
DescriptionColorLEDIndicator (Label)
RSP in initializing or failed state.RedBi-colorRSP FAIL
RSP is up and running.Green
RSP is normal.Off
LC in initializing or failed state.Red
Bi-colorLC FAIL
(Cisco ASR 9001)
LC is up and running.Green
LC is normal.Off
LC in initializing or failed state.
Note: When power is connected to the chassis but the chassis
power switch is set to the OFF position, the LED is red and
all other LEDs are off.
Red
Bi-colorLC STAT/INPUT OK
(Cisco ASR 9901)
LC is up and running.Green
LC is powered off. The LED might turn off momentarily
when switching between the states described above, although
the LC has not powered off.
Off
Critical Alarm LED. A critical alarm has occurred.Red
Single colorCritical Alarm (CRIT)
No critical alarm has occurred.Off (Default after
reset)
Major alarm LED. A major alarm has occurred.Red
Single colorMajor Alarm (MAJ)
No major alarm has occurred.Off (Default after
reset)
Minor alarm LED. A minor alarm has occurred.Amber
Single colorMinor Alarm (MIN)
No minor alarm has occurred.Off (Default after
reset)
