Catalyst 6500 Series Content Switching Module Configuration Note
OL-4612-01
Chapter 6 Configuring Virtual Servers, Maps, and Policies
Configuring Virtual Servers
This example shows how to configure a virtual server named barnett, associate it with the server farm
named bosco, and configure a sticky connection with a duration of 50 minutes to sticky group 12:
Router(config)# mod csm 2
Router(config-module-csm)# sticky 1 cookie foo timeout 100
Router(config-module-csm)# exit
Router(config-module-csm)#
Router(config-module-csm)# serverfarm bosco
Router(config-slb-sfarm)# real 10.1.0.105
Router(config-slb-real)# inservice
Router(config-slb-real)# exit
Router(config-slb-sfarm)#
Router(config-slb-sfarm)# vserver barnett
Router(config-slb-vserver)# virtual 10.1.0.85 tcp 80
Router(config-slb-vserver)# serverfarm bosco
Router(config-slb-vserver)# sticky 50 group 12
Router(config-slb-vserver)# inservice
Router(config-slb-vserver)# exit
Router(config-module-csm)# end
This example shows how to configure a virtual server, named vs1, with two policies and a default server
farm when client traffic matches a specific policy. The virtual server will be load balanced to the server
farm attached to that policy. When client traffic fails to match any policy, the virtual server will be load
balanced to the default server farm named bosco.
Router(config)# mod csm 2
Router(config-module-csm)# map map3 url
Router(config-slb-map-url)# match protocol http url *finance*
Router(config-slb-map-url)#
Router(config-slb-map-url)# map map4 url
Router(config-slb-map-url)# match protocol http url *mail*
Router(config-slb-map-url)#
Router(config-slb-map-url)# serverfarm bar1
Router(config-slb-sfarm)# real 10.1.0.105
Router(config-slb-real)# inservice
Router(config-slb-real)#
Router(config-slb-real)# serverfarm bar2
Router(config-slb-sfarm)# real 10.1.0.106
Router(config-slb-real)# inservice
Router(config-slb-real)#
Router(config-slb-real)# serverfarm bosco
Router(config-slb-sfarm)# real 10.1.0.107
Router(config-slb-real)# inservice
Router(config-slb-real)#
Router(config-slb-real)# policy pc1
Router(config-slb-policy)# serverfarm bar1
Router(config-slb-policy)# url-map map3
Router(config-slb-policy)# exit
Router(config-module-csm)#
Router(config-module-csm)# policy pc2
Router(config-slb-policy)# serverfarm bar2
Step 10
Router(config-slb-vserver)# inservice
Enables the virtual server for use by the CSM
2
.
Step 11
Router# show module csm slot vserver
[details]
Displays information for virtual servers defined for
content switching.
1. Enter the exit command to leave a mode or submode. Enter the end command to return to the menu’s top level.
2. The no form of this command restores the defaults.
3. These parameters refer to the default policy.
Command Purpose
