Cisco IE 3000 User Manual

33-8
Cisco IE 3000 Switch Software Configuration Guide
OL-13018-01
Chapter 33 Configuring EtherChannels and Link-State Tracking
Configuring EtherChannels
Figure 33-3 Load Distribution and Forwarding Methods
Configuring EtherChannels
These sections contain this configuration information:
• Default EtherChannel Configuration, page 33-9
• EtherChannel Configuration Guidelines, page 33-9
• Configuring Layer 2 EtherChannels, page 33-10 (required)
• Configuring EtherChannel Load Balancing, page 33-12 (optional)
• Configuring the PAgP Learn Method and Priority, page 33-13 (optional)
• Configuring LACP Hot-Standby Ports, page 33-14 (optional)
Note Make sure that the ports are correctly configured. For more information, see the “EtherChannel
Configuration Guidelines” section on page 33-9.
Note After you configure an EtherChannel, configuration changes applied to the port-channel interface apply
to all the physical ports assigned to the port-channel interface, and configuration changes applied to the
physical port affect only the port where you apply the configuration.
101239
Cisco router
with destination-based
forwarding enabled
EtherChannel
Switch with
source-based
forwarding enabled

Cisco IE 3000 Specifications

General

Operating Temperature	-40 to 75°C (-40 to 167°F)
DRAM	128 MB
Flash Memory	32 MB
Uplink Ports	2 x 10/100/1000Base-T or SFP
MAC Address Table Size	8000
Mounting	DIN rail, Wall
