Cisco IE 3000 User Manual

13-26
Cisco IE 3000 Switch Software Configuration Guide
OL-13018-01
Chapter 13 Configuring VLANs
Configuring VMPS
Entering the IP Address of the VMPS
You must first enter the IP address of the server to configure the switch as a client.
Note If the VMPS is being defined for a cluster of switches, enter the address on the command switch.
Beginning in privileged EXEC mode, follow these steps to enter the IP address of the VMPS:
Note You must have IP connectivity to the VMPS for dynamic-access ports to work. You can test for IP
connectivity by pinging the IP address of the VMPS and verifying that you get a response.
Configuring Dynamic-Access Ports on VMPS Clients
If you are configuring a port on a cluster member switch as a dynamic-access port, first use the
rcommand privileged EXEC command to log in to the cluster member switch.
Caution Dynamic-access port VLAN membership is for end stations or hubs connected to end stations.
Connecting dynamic-access ports to other switches can cause a loss of connectivity.
Beginning in privileged EXEC mode, follow these steps to configure a dynamic-access port on a VMPS
client switch:
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
vmps server ipaddress primary Enter the IP address of the switch acting as the primary VMPS server.
Step 3
vmps server ipaddress (Optional) Enter the IP address of the switch acting as a secondary VMPS
server.
You can enter up to three secondary server addresses.
Step 4
end Return to privileged EXEC mode.
Step 5
show vmps Verify your entries in the VMPS Domain Server field of the display.
Step 6
copy running-config startup-config (Optional) Save your entries in the configuration file.
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
interface interface-id Specify the switch port that is connected to the end station, and enter
interface configuration mode.
Step 3
switchport mode access Set the port to access mode.
Step 4
switchport access vlan dynamic Configure the port as eligible for dynamic VLAN membership.
The dynamic-access port must be connected to an end station.
Step 5
end Return to privileged EXEC mode.

Cisco IE 3000 Specifications

General

Operating Temperature	-40 to 75°C (-40 to 167°F)
DRAM	128 MB
Flash Memory	32 MB
Uplink Ports	2 x 10/100/1000Base-T or SFP
MAC Address Table Size	8000
Mounting	DIN rail, Wall
